Инверторный кондиционер колонного типа

MIDEA MFYA400-24ARFN1

24000btu-28000btu İnverter Salon Tipi Klima
₺ 15,576 ₺ 19,470

A+/A++

24000btu İnverter Klima

Power supply Ph-V-Hz 220-240V,1Ph,50Hz

Cooling Capacity:
- Btu/h 24000(2340~29100)

- Input W 2340(570~3600)

-Rated current A 10.4(2.5~16.0)

- EER W/W 3.01

Heating Capacity:

- Btu/h 26000(9600~33400)

- Input W 2000(1450~3150)

- Rated current A 8.9(6.7~14.0)

- COP W/W 3.81

Seasonal Cooling:

- Pdesignc kW 7.0

- SEER W/W 6.1

- Energy Efficiency Class A++

Heating(Warmer ):

- Pdesignh kW 5.7

-  SCOP W/W 4.6

-  Energy Efficiency Class A++

 - Tbiv ℃ 2

Tol ℃ -10

Max. input consumption W 4850

Max. current A 20

 Indoor air flow (Hi/Mi/Lo) m3/h 990/760/640

Indoor noise level (Hi/Mi/Lo) dB(A) 39.5/37.5/34.5

Indoor sound power level dB(A) 59

Indoor unit Dimension(W*D*H) mm 405x405x1775

 Packing (W*D*H) mm 2000x510x490

 Net/Gross weight Kg 29.9/38.4

Outdoor fan motor Model ZKFN-80-8-3

 Input W 88.0

 Capacitor uF /

 Speed r/min 830/730/550

Outdoor air flow m3/h 3500

Outdoor noise level dB(A) 58.5

Outdoor sound power level dB(A) 68

Outdoor unit Dimension(W*D*H) mm 890x342x673

 Packing (W*D*H) mm 995x398x740

 Net/Gross weight Kg 44.7/47.9

Refrigerant type Kg R410A/1.95

Design pressure MPa 4.2/1.5

Refrigerant piping Liquid side/ Gas side mm(inch) 6.35mm(1/4in)/12.7mm(1/2in)

 Max. refrigerant pipe length m 50

 Max. difference in level m 25

Connection wiring 1.5x4//

Plug type //no-plug

Thermostat type Remote Control

Operation temperature ℃ 17~30

Room temperature Indoor(cooling/ heating) ℃ 17~32/0~30

 Outdoor(cooling/heating) ℃ -15~50/-15~24

Application area (Cooling Standard) m2 32~47

Qty’per 20’ /40’ /40'HQ 28/64/75
